Replacement Dental Lamps
We can customize the lamp length and diameter per your requirements. Our minimum order quantity for Custom lamps is 100pcs. For the best price and lead time, please email or give us a call.

Germicidal UV Lamps

The Ultraviolet light is classified in three ranges of wavelength:
UV-A from 315nm to 400nm
UV-B from 280nm to 315nm
UV-C from 100nm to 280nm
We can offer UV-A 350nm and 360nm and Germicidal Lamps 254nm that is part of UV-C.

UV-C Cold Cathode 254nm Germicidal Lamps
Quartz Germicidal Lamps are low pressure lamps that generate most of the energy at 254nm (253,7nm - Mercury line) and some energy at 185nm. In medical terminology they are known as UV-C lamps. The mechanical structure of a germicidal lamps is the same as for a Miniature Cold Cathode Florescent Lamp but instead glass the envelope is manufactured with quartz. At these wavelength the most bacteria, spores and viruses are complete destroyed.

As major applications we can mention:
  • Air Disinfection. It is recommended in the area commonly used by people suspected to be infected with Airborne transmitted diseases such us: physician waiting room, hospital waiting room, surgical, room, holding areas, treatment rooms, veterinary and pet facilities, and everywhere where people and/or animals are congregating. Since UV radiation is harmful to human eyes, it is mandatory to avoid direct exposure to UV radiation/light using proper mounting fixtures for these lamps. To accelerate the lamp germicidal effect it is highly recommended a good ventilation/movement of the air using a small fun that will mixed the treated with untreated air, diminishing the concentration of the air born microorganism and bacteria.
  • Air Ozonation. Ozone has odor neutralization ability. The UV-185 energy radiation breaks apart some of the Oxygen molecules (O2) into two radicals Oxygen (O-) that combines and forms Ozone (O3).The combined odor neutralization and germicidal effects make UV-C lamps a very low cost methode.
  • Water Disinfection. For many years it is very well known that one of the radiation effects at 254nm is water disinfection with no residual or side effect. Using the UV disinfection system will keep the water free of any bacteria or other organic materials that can grow. UV-254nm radiation is one of the most effective water disinfection method without any residual or side effects. The cost of operation versus chemical methode is very low.
  • Chlorine Removal. Exposing the water to UV-185nm generated by the quartz cold cathode lamps will also lead to a photochemical reaction similarly with the sun radiation. Through photochemical reaction the chlorine disassociates to chlorine ion
    (Cl-) and Hydrochloric Acid (HCl) which can be easy removed
    from the water.
  • Carbon Reduction. Semiconductor Processing Industry requires a high purity of water with no organic based components. The presence of carbon in water can be very efficient minimized exposing the water to UV -185nm germicidal radiation. Under UV radiation some of the water molecules are discomposing on H and OH. As OH radical is a very powerful oxidant all the residual carbon will be transformed in CO2. Typical dosage required may vary between 100mWsec/cm2 to 900mWsec/cm2
  • Sterilization Time. Sterilization time in second = Sterilization Dosage/Radiation Intensity Sterilization Dosage (uW, sec/cm2) = UV intensity * Exposure Time Radiation Intensity (uW/cm2) = UV Intensity / cm2. Our Miniature Quartz Cold Cathode lamps generate min. 5mW/cm2 (typical 6mW/cm2) One of the most resistant virus is Tuberculosis. The energy needed for total destruction is 10mW/cm2. The efficient sterilization dosage for a certain surface that should be sterilized is: 10mWsec/cm2 / 5mW/cm2 = 2 seconds. This should be the total time that surface we want to disinfect should remain under UV radiation. To calculate the sterilization dosage for water or air we may need to take in account a certain number of factors such us: lamp intensity radiation, intensity variation within distance, the chamber size, the flow rate, the absorbtion coefficient of the media, etc
    .
UV-A 350nm or 360nm Cold Cathode Lamps
  • As major applications we can mention: backlight, special art effects, glowing UV fluorescent dyes, glowing invisible ink, detective work for authentication of art or collectables, analyzing minerals and gems, checking electrical insulation by checking corona discharge, curing of adhesives and coatings sensitive to UV, insect traps, spectrophotometry, etc.

CAUTION!
Germicidal Cold Cathode lamps are manufactured with quartz glass. The lamp is filled with gas and a very small amount of Mercury – less than 5mg per lamp. These lamps generate UV radiation at 254nm. There is also a small amount of Ozone generated by the residual radiation of 195nm and corona effect. The voltage supplied to activate the lamp is over 300V and is direct proportional with the lamp length. Longer lamps needs over 1000V.

SAFETY CONCERNS:
• Although the amount of UV and Ozone generation is very small (UV is Max. 5.0mW/cm2), we recommend all suitable precaution to avoid eyes or skin exposure to UV radiation. It can produce serious damage to the eye, which may lead to temporary or permanent vision impairment. For this reason, the light produced by a germicidal lamp must be carefully shielded against both direct viewing and reflections and dispersed light that might be viewed.
• Do not touch the glass/quartz with the bare hands.
• Use appropriate protection, wires and insulated materials to avoid surge voltage from the lamp leads.
• Discard the lamps in accordance with safety cod requirements for materials containing Mercury.
• Take also all suitable requirements recommended by the government safety code to avoid a prolong inhalation of Ozone generated by the lamp.

UV Lamps and kits currently in Stock

MCCUV-50/5 254nm
UV Germicidal Lamp 254nm, 50mm length by 5mm dia.
Click here for complete specifications
$16.58
(pack of 2)

MCCUV-75/5 254nm
UV Germicidal Lamp 254nm, 75mm length by 5mm dia.
Click here for complete specifications
$16.68
(pack of 2)

MCCUV-100/5 254nm
UV Germicidal Lamp 254nm, 100mm length by 5mm dia.
Click here for complete specifications
$16.78
(pack of 2)

UV-C 254nm Germicidal 150mm Dual Lamp 12V DC Kit
Kit includes:
2pcs UV Germicidal Lamp 150mm length by 5mm diameter
1pcs 12V DC High Power Dual Lamp Inverter with attached low voltage wire
2pcs High Voltage Wire 150mm length
Click here for lamp specifications
$24.99 Now $21.99

MCCUV-150/5 254nm
UV Germicidal Lamp 254nm, 150mm length by 5mm dia.
$16.88
(pack of 2)

UV-C 254nm Germicidal 100mmx 12mm Lamp 12V DC Kit
Kit includes:
1pcs UV Germicidal Lamp 100mm length x 12mm dia. with attached wires
1pcs 12V DC Single Lamp Inverter
1pcs Low Voltage Wire 150mm length
Click here for complete specifications
$17.99

UV-C 254nm Germicidal 100mmx 12mm Dual Lamp 12V DC Kit
Kit includes:
2pcs UV Germicidal Lamp 100mm length x 12mm dia. with attached wires
1pcs 12V DC Dual Lamp Inverter
1pcs Low Voltage Wire 150mm length
Click here for complete specifications
$24.99

UV-C Germicidal 254nm Dual U-shape 150mm Lamp 12V DC Kit
Kit includes:
2pcs – UV Germicidal Lamp 254nm U-Shape 150x10x150mm w/harness & connector
1pcs – 12V DC Dual Lamp Inverter with Shell
1pcs – Low Voltage wire 100mm length

Click here for complete specifications
$24.99



UV-C 254nm Germicidal Ushape 55x8x55mm Dual Lamp 5V DC Kit
Kit includes:
2pcs UV Germicidal Lamp U-Shape 55mm x 8mm x 55mm
1pcs 5V DC Dual Lamp Inverter
2pcs High Voltage Wire 250mm length
1pcs Low Voltage Wire 150mm length
Click here for lamp specifications
$22.79

UV-C 254nm Germicidal Ushape 75x8x75mm Dual Lamp 12V DC Kit
Kit includes:
2pcs UV Germicidal Lamp U-Shape 75mm x 8mm x 75mm
1pcs 12V DC Dual Lamp Inverter
2pcs High Voltage Wire 250mm length
1pcs Low Voltage Wire 150mm length
Click here for lamp specifications
$22.89

UV-C 254nm Germicidal Ushape 100x8x100mm Dual Lamp 12V DC Kit
Kit includes:
2pcs UV Germicidal Lamp U-Shape 100mm x 8mm x 100mm
1pcs 12V DC Dual Lamp Inverter
2pcs High Voltage Wire 250mm length
1pcs Low Voltage Wire 150mm length
Click here for lamp specifications
$22.99

UV-C 254nm Germicidal Ushape 55x8x55mm Single Lamp 12V DC Kit
Kit includes:
1pcs UV Germicidal Lamp 55mm length by 4mm diameter
1pcs 12V DC Single Lamp Inverter with shell & attached high and low voltage wires
Click here for lamp specifications
$15.49

MCCUV-C-55x8x55 254nm
UV-C Germicidal Lamp 254nm, 55mmx8mmx55mm, 4mm dia.
Click here for complete specifications
$17.58
(pack of 2)

MCCUV-C-75x8x75 254nm
UV-C Germicidal Lamp 254nm, 75mmx8mmx75mm, 4mm dia.
Click here for complete specifications
$17.68
(pack of 2)

MCCUV-C-100x8x100 254nm
UV-C Germicidal Lamp 254nm, 100mmx8mmx100mm, 4mm dia.
Click here for complete specifications
$17.78
(pack of 2)

.
5V Dual Lamp Inverter, Part No. INV-2L-5V-200
(for use with lamps up to 150mm)
The inverter is designed to supply the Cold Cathode Lamp with correct voltage for lamps up to 200mm length. First, it will supply a starting voltage up to 700-750 vrms. Then the voltage will drop supplying the lamp a constant current of 4-6 mA at 40-50 KHz. To power the lamp we highly recommend our invertors designed for each type of lamp length.
Click for complete specifications
Price: $5.89

12V Single Lamp Inverter, Part No. INV-1L-12V-200
The inverter is designed to supply the Cold Cathode Lamp with correct voltage for lamps up to 200mm length. First, it will supply a starting voltage up to 700-750 vrms. Then the voltage will drop supplying the lamp a constant current of 4-6 mA at 40-50 KHz. To power the lamp we highly recommend our invertors designed for each type of lamp length.
Click for complete specifications
Price: $4.99

12V Single Lamp Inverter with shell and attached high & low voltage wires,
Part No. INV-1L-12V-200S
The inverter is designed to supply the Cold Cathode Lamp with correct voltage for lamps up to 200mm length. First, it will supply a starting voltage up to 700-750 vrms. Then the voltage will drop supplying the lamp a constant current of 4-6 mA at 40-50 KHz. To power the lamp we highly recommend our invertors designed for each type of lamp length.
Click for complete specifications
Price: $6.99

12V Dual Lamp Inverter, Part No. INV-2L-12V-200
The inverter is designed to supply the Cold Cathode Lamp with correct voltage for lamps up to 200mm length. First, it will supply a starting voltage up to 700-750 vrms. Then the voltage will drop supplying the lamp a constant current of 4-6 mA at 40-50 KHz. To power the lamp we highly recommend our invertors designed for each type of lamp length.
Click for complete specifications
Price: $5.89

12V Single Lamp Inverter, Part No. INV-1L-12V-300
The inverter is designed to supply the Cold Cathode Lamp with correct voltage for lamps up to 300mm length. First, it will supply a starting voltage up to 900-950 vrms. Then the voltage will drop supplying the lamp a constant current of 4-6 mA at 40-50 KHz. To power the lamp we highly recommend our invertors designed for each type of lamp length.
Click for complete specifications
Price: $4.99

12V Dual Lamp Inverter, Part No. INV-2L-12V-300
The inverter is designed to supply the Cold Cathode Lamp with correct voltage for lamps up to 300mm length. First, it will supply a starting voltage up to 900-950 vrms. Then the voltage will drop supplying the lamp a constant current of 4-6 mA at 40-50 KHz. To power the lamp we highly recommend our invertors designed for each type of lamp length.
Click for complete specifications
Price: $5.89

120V Dual Lamp Inverter, Part No. INV-2L-120
The inverter is designed to supply the Cold Cathode Lamp with correct voltage. First, it will supply a starting voltage up to 900-950 vrms. Then the voltage will drop supplying the lamp a constant current of 4-9 mA at 40-50 KHz. To power the lamp we highly recommend our invertors designed for each type of lamp length.
Click for complete specifications
Special Order Only Min. 100pcs

220V Dual Lamp Inverter Part No. INV-2L-220
The inverter is designed to supply the Cold Cathode Lamp with correct voltage. First, it will supply a starting voltage up to 900-950 vrms. Then the voltage will drop supplying the lamp a constant current of 4-9 mA at 40-50 KHz. To power the lamp we highly recommend our invertors designed for each type of lamp length.
Special Order Only Min. 100pcs

High and low voltage wires Part No. HV250-LV150
High voltage wire is 250mm long, and the low voltage wire is 150mm long.
Price: $1.39 per pack.
